Product Overview
Vibro Acoustics CM-1N-150, 1" (25 mm) Deflection CM Closed Mount Spring Isolators, 150 lbs rated load, Orange. 1 inch deflection at rated load, 6 lbs isolator weight. Laterally supported, housed spring type isolator with telescoping equipment support plate, leveling bolt and hold-down nut for attaching equipment.
Springs are supported with a cup on a metal base plate complete with a ribbed neoprene vibration isolation pad, 1/4" (6 mm) thick, bonded to the base plate.
Steel telescoping housing incorporates neoprene stabilzers that prevent metal-to-metal contact while resisting movement and provides vertical damping.
Minimum 50% additional travel to solid
Minimum kx/ky ratio of 0.8
Springs are supported with a cup on a metal base plate complete with a ribbed neoprene vibration isolation pad, 1/4" (6 mm) thick, bonded to the base plate.
Steel telescoping housing incorporates neoprene stabilzers that prevent metal-to-metal contact while resisting movement and provides vertical damping.
Minimum 50% additional travel to solid
Minimum kx/ky ratio of 0.8
